IP20 24V Seamless COB LED Strip 5m - RGB

156.667UK

Multi-colour RGB COB LED Strip by Lyyt provides a continuous linear lighting solution. The COB (chip on board) technology consists of 840 tightly packed LEDs per metre. The flexible COB strip is su...

  • 840 LED's/m
  • Self-adhesive backing for easy installation
  • Low voltage (24Vdc) and power consumption
Full description Find retailer
Description Version Packed
156.667UK
IP20 24V COB LED Strip 5m - RGB 		IP20 RGB Poly Bag

Accessories

Description Version Packed
156.657UK
RGB COB Flexible Link - 5 Pack 		RGB 10mm Poly Bag
156.656UK
RGB COB Connector 		10mm Tape to Tape Poly Bag
153.743UK
RGBW Sound Active Controller 		Box Label
153.759UK
Power Supply 24Vdc 2.50A 60W 		24Vdc 2.50A 60W Box Label
153.760UK
Power Supply 24Vdc 4.16A 100W 		24Vdc 4.16A 100W Box Label
153.761UK
Power Supply 24Vdc 6.25A 150W 		24Vdc 6.25A 150W Box Label
153.762UK
Power Supply 24Vdc 8.33A 200W 		24Vdc 8.33A 200W Box Label
153.763UK
Power Supply 24Vdc 10.4A 250W 		24Vdc 10.4A 250W Box Label
153.764UK
Power Supply 24Vdc 12.5A 300W 		24Vdc 12.5A 300W Box Label
153.771UK
In-line RGB LED tape amplifier with DC socket 		Poly Bag
153.896UK
RGBW WiFi Touch Wall Controller 		RGBW WiFi Poly Bag
153.797UK
RGB LED Tape Controller DC 		Poly Bag
153.777UK
12-24V RGB DMX Controller 		RGB 3x8A Box Label
153.900UK
RGB LED Tape Y-Splitter Lead 		Splitter Lead 0.3m Poly Bag
153.903UK
RGB LED Tape Extension Lead 3.0m 		Extension Lead 3.0m Poly Bag
153.905UK
RGB LED Tape Extension Lead 5.0m 		Extension Lead 5.0m Poly Bag
777.000UK
2.1mm DC Plug with screw in terminals 		Poly Bag
777.001UK
2.1mm DC Socket with screw in terminals 		Poly Bag
156.654UK
RGB COB Connector L 5pk 		10mm L Poly Bag
156.652UK
RGB COB Connector T 5pk 		10mm T Poly Bag
156.650UK
RGB COB Connector X 5pk 		10mm X Poly Bag

IP20 24V Seamless COB LED Strip 5m - RGB

Multi-colour RGB COB LED Strip by Lyyt provides a continuous linear lighting solution. The COB (chip on board) technology consists of 840 tightly packed LEDs per metre. The flexible COB strip is supplied on a 5m reel and can be cut to desired length along the designated cutting points, the strip is equipped with an adhesive backing for easy installation. The 24Vdc COB strip is suitable for a wide variety of applications, such as in hospitality, retail, offices, displays, exhibitions and more. IP20 versions are for indoor use only.

  • 840 LED's/m
  • Self-adhesive backing for easy installation
  • Low voltage (24Vdc) and power consumption
  • Flexible and lightweight
  • Features 4pin male and 4pin female connectors
  • Voltage 24Vdc
  • Number of LEDs 840/m
  • Beam angle 120°
  • Cut intervals 50mm
  • Reel length 5m
  • LED : type Sanan
  • LED : spacing 0.97mm
  • Current 485mA/m
  • Power consumption per metre 11.64W/m
  • Colour rendering index (CRI, Ra) Ra>80
  • Cross-section 10 x 2.2mm
  • IP rating IP20
  • Colour RGB
  • Lumens 100lm/w
  • Weight 0.126kg

In the box

The box for this item contains :

  • 1 x 5m RGB COB LED Strip

Downloads

Instruction manual
For 156.667UK (203KB)
UK Declaration of conformity
For 156.667UK (247KB)
EU Declaration of conformity
For 156.667UK (235KB)
