3m DIY LED Tape Kit - IP65 RGB

156.727UK DK3-RGB30

Retail ready blister packed RGB LED tape with multi-region power adaptor. The tape has an adhesive backing and an epoxy coating to provide IP65 weatherproofing. Low voltage operation makes this tap...

  • 30 x SMD5050 LEDs per metre
  • Self-adhesive backing for easy installation
  • Can be cut at 10cm intervals
Full description Find retailer
Description Version Packed
156.727UK
3m LED Tape Kit - RGB 		RGB Hanging Bag

Accessories

Description Version Packed
153.900UK
RGB LED Tape Y-Splitter Lead 		Splitter Lead 0.3m Poly Bag
153.903UK
RGB LED Tape Extension Lead 3.0m 		Extension Lead 3.0m Poly Bag
153.905UK
RGB LED Tape Extension Lead 5.0m 		Extension Lead 5.0m Poly Bag
156.136UK
10mm RGB LED tape L connector - pack of 5 		10mm RGB L piece Poly Bag
156.138UK
10mm RGB LED tape T connector - pack of 5 		10mm RGB T piece Poly Bag
156.140UK
10mm RGB LED tape X connector - pack of 5 		10mm RGB X piece Poly Bag

3m DIY LED Tape Kit - IP65 RGB

Retail ready blister packed RGB LED tape with multi-region power adaptor. The tape has an adhesive backing and an epoxy coating to provide IP65 weatherproofing. Low voltage operation makes this tape safe to use around the home and convenient for vehicle or mobile home installation.

  • 30 x SMD5050 LEDs per metre
  • Self-adhesive backing for easy installation
  • Can be cut at 10cm intervals
  • IP65 rated
  • Low voltage operation
  • Includes IR remote controller
  • Supplied with 12Vdc UK power adaptor
  • Power supply 12Vdc, 2000mA
  • Number of LEDs 30/m
  • Beam angle 130° - 150°
  • Cut intervals 10cm
  • Reel length 3m
  • LED : type SMD5050 RGB
  • IP rating IP65
  • LED : spacing 32mm
  • Current 600mA/m
  • Lumens per LED 16lm
  • Power consumption per metre 7.2W/m
  • Cross-section 10 x 2.4mm
  • Weight (3m reel) 120g

Support : articles

IP ratings

IP (or "Ingress Protection") ratings are used to define levels of sealing effectiveness of electrical enclosures against intrusion from foreign bodies (tools, dirt etc) and moisture.

Sunday, 1st January 2017

Downloads

Instruction manual
For 156.727UK (339KB)
UK Declaration of conformity
For 156.727UK (244KB)
EU Declaration of conformity
For 156.727UK (233KB)
