IP65 DIY LED Tape - 5m Multi-colour RGB

153.727UK DIY-RGB30

Retail ready packaged RGB LED tape together with a mains power adaptor, IR controller and connection accessories. The tape has a transparent coating to provide weatherproof protection and can be cu...

  • 30 x SMD5050 LEDs per metre
  • Self-adhesive backing for easy installation
  • Can be cut at 10cm intervals
Description Version Packed
153.727UK
LED tape 5m - Multi-colour RGB
RGB Gift Box

Accessories

Description Version Packed
153.900UK
RGB LED Tape Y-Splitter Lead
Splitter Lead 0.3m Poly Bag
153.903UK
RGB LED Tape Extension Lead 3.0m
Extension Lead 3.0m Poly Bag
153.905UK
RGB LED Tape Extension Lead 5.0m
Extension Lead 5.0m Poly Bag
156.136UK
10mm RGB LED tape L connector - pack of 5
10mm RGB L piece Poly Bag
156.138UK
10mm RGB LED tape T connector - pack of 5
10mm RGB T piece Poly Bag
156.140UK
10mm RGB LED tape X connector - pack of 5
10mm RGB X piece Poly Bag
153.741UK
RGB Controller for LED tape with IR remote control
Box Label
153.751UK
RGB Tape controller with 44 key multi function IR remote
Box Label
153.771UK
In-line RGB LED tape amplifier with DC socket
Poly Bag
153.777UK
12-24V RGB DMX Controller
RGB 3x8A Box Label
153.797UK
RGB LED Tape Controller DC
Poly Bag
156.148UK
DIY RGB Flexible Link - Pack of 5
10mm RGB Poly Bag
153.744UK
Power Supply 12Vdc 5A 60W
12Vdc 5A 60W Box Label
153.753UK
Power Supply 12Vdc 3.75A 45W
12Vdc 3.75A 45W Box Label
153.754UK
Power Supply 12Vdc 2.5A 30W
12Vdc 2.5A 30W Box Label
153.755UK
Power Supply 12Vdc 8.3A 100W
12Vdc 8.3A 100W Box Label
153.756UK
Power Supply 12Vdc 12.5A 150W
12Vdc 12.5A 150W Box Label
777.000UK
2.1mm DC Plug with screw in terminals
Poly Bag
777.001UK
2.1mm DC Socket with screw in terminals
Poly Bag

IP65 DIY LED Tape - 5m Multi-colour RGB

Retail ready packaged RGB LED tape together with a mains power adaptor, IR controller and connection accessories. The tape has a transparent coating to provide weatherproof protection and can be cut to length as required. Low voltage 12Vdc inline power supply. Allowing for the option of integrating into a fixed installation, which provides a discrete power solution. Self adhesive backing allows for quick and easy installation in the home, motor home, or vehicles.

  • 30 x SMD5050 LEDs per metre
  • Self-adhesive backing for easy installation
  • Can be cut at 10cm intervals
  • IP65 rated
  • Low voltage operation
  • Includes IR remote controller
  • Supplied with 12Vdc UK Power Supply
  • Can extend beyond 5m with an RGB amplifier 153.771UK and splitter 153.900UK (not supplied)
  • Power supply 12Vdc
  • Number of LEDs 30/m
  • Beam angle 130 - 150°
  • Cut intervals 10cm
  • Reel length 5m
  • LED : type SMD5050 RGB
  • IP rating IP65
  • LED : spacing 32mm
  • Current 600mA/m
  • Lumens per LED 16lm
  • Power consumption per metre 7.2W
  • Cross-section 10 x 2.4mm
  • Weight 230g

Support : articles

IP ratings

IP (or "Ingress Protection") ratings are used to define levels of sealing effectiveness of electrical enclosures against intrusion from foreign bodies (tools, dirt etc) and moisture.

Sunday, 1st January 2017

Videos

IP65 DIY LED Tape - 5m Multi-colour RGB

Downloads

Instruction manual
For 153.727UK (339KB)
UK Declaration of conformity
For 153.727UK (245KB)
EU Declaration of conformity
For 153.727UK (234KB)
