12V Warm & Cool White LED Tape - 5m Reel

156.719UK LT12560-CCT

5m reel of LED tape with 60 x SMD5050 dual colour LEDs per metre with mixable warm and cool white colour output. Cutting points at every 5cm for custom lengths. 12Vdc power in and out connections a...

  • Warm and cool white on each LED chip
  • 60 high output SMD5050 LEDs per metre
  • Can be mixed or switched for variable CCT output
Full description Find retailer
Description Version Packed
156.719UK
12V warm / cool white LED tape 60 per metre 		Warm/Cool White Poly Bag

12V Warm & Cool White LED Tape - 5m Reel

5m reel of LED tape with 60 x SMD5050 dual colour LEDs per metre with mixable warm and cool white colour output. Cutting points at every 5cm for custom lengths. 12Vdc power in and out connections are via locking DC5521 jacks. Can be connected to 2 switches or combined with a 2 colour controller for variable Correlated Colour Temperature (CCT).

  • Warm and cool white on each LED chip
  • 60 high output SMD5050 LEDs per metre
  • Can be mixed or switched for variable CCT output
  • Self-adhesive backing for easy installation
  • IP65 rated
  • Voltage 12Vdc
  • LED : quantity per metre 60
  • Power consumption per metre 9.6W/m
  • Current 800mA per metre
  • Beam angle 140°
  • LED : colour Warm white (3000K) + cool white (6000K)
  • LED : type SMD5050 dual colour
  • Luminous flux (Lumens per metre) 600lm/m
  • Light intensity per LED (millicandelas) 6000mcd
  • Cut intervals 5cm
  • LED : spacing 16mm
  • Reel length 5m
  • IP rating IP65
  • Cross-section 10.5 x 3.2mm
  • Weight 230g

Downloads

Instruction manual
For 156.719UK (311KB)
UK Declaration of conformity
For 156.719UK (247KB)
EU Declaration of conformity
For 156.719UK (237KB)
