19" Flightcases for Audio Equipment
171.430UK
RACK:6U
Flightcases for mounting 19" audio equipment. Fitted with heavy duty handles, protective corner pieces and removable front and rear lids. Made from 9mm plywood with washers on all the rivets to str...
- Ideal for safe transport of your expensive equipment
- 9mm vinyl laminated plywood construction
- Fitted with heavy duty handles, protective corner pieces and removable lids
| Description | |
|---|---|
|
171.730UK
19'' equipment flightcase - 2U |
|
171.733UK
19'' equipment flightcase - 3U |
|
171.426UK
19'' equipment flightcase - 4U (shallow) |
|
171.427UK
19'' equipment flightcase - 4U |
|
171.430UK
19'' equipment flightcase - 6U |
|
171.433UK
19'' equipment flightcase - 8U |
|
171.436UK
19'' equipment flightcase - 10U |
|
171.736UK
19'' equipment flightcase - 12U |
|
171.739UK
19'' equipment flightcase - 16U |
19" Flightcases for Audio Equipment
Flightcases for mounting 19" audio equipment. Fitted with heavy duty handles, protective corner pieces and removable front and rear lids. Made from 9mm plywood with washers on all the rivets to strengthen and protect the wood from splitting.
- Ideal for safe transport of your expensive equipment
- 9mm vinyl laminated plywood construction
- Fitted with heavy duty handles, protective corner pieces and removable lids
- Available in 2, 3, 4, 6, 8, 10, 12 and 16U versions
Specification : Versions
| 171.730UK | 171.733UK | 171.426UK | 171.427UK | 171.430UK | 171.433UK | 171.436UK | 171.736UK | 171.739UK | |
|---|---|---|---|---|---|---|---|---|---|
| Size | 2U | 3U | 4U short | 4U | 6U | 8U | 10U | 12U | 16U |
| External dimensions | 630 x 135 x 535mm | 625 x 180 x 535mm | 450 x 225 x 535mm | 635 x 230 x 535mm | 635 x 310 x 535mm | 635 x 410 x 535mm | 695 x 490 x 535mm | 695 x 585 x 535mm | 687 x 755 x 535mm |
| Internal dimensions | 460 x 100 x 500mm | 470 x 150 x 500mm | 280 x 185 x 500mm | 460 x 190 x 500mm | 460 x 275 x 500mm | 465 x 365 x 500mm | 525 x 455 x 500mm | 525 x 540 x 500mm | 520 x 720 x 500mm |
| Fixing rails | Front | Front | Front | Front | Front | Front and rear | Front and rear | Front and rear | Front and rear |
| Weight | 6kg | 7kg | 9kg | 9kg | 12kg | 17kg | 21kg | 22kg | 24kg |
Trade information
| 171.730UK | 171.733UK | 171.426UK | 171.427UK | 171.430UK | 171.433UK | 171.436UK | 171.736UK | 171.739UK | |
|---|---|---|---|---|---|---|---|---|---|
| Barcode / EAN | 5015972031124 | 5015972031131 | 5015972030707 | 5015972030714 | 5015972030721 | 5015972030738 | 5015972030745 | 5015972031148 | 5015972031155 |
| Tariff code | 8529904100 | 8529904100 | 8529904100 | 8529904100 | 8529904100 | 8529904100 | 8529904100 | 8529904100 | 8529904100 |
| Country of Origin | CN | CN | CN | CN | CN | CN | CN | CN | CN |
| Package type | Box Plain | Box Plain | Box Label BW | Box Plain | Box Plain | Box Plain | Box Plain | Box Plain | Box Plain |
| Package dimensions | 550 x 155 x 625mm | 550 x 199 x 625mm | 560 x 255 x 465mm | 560 x 255 x 652mm | 560 x 342 x 652mm | 560 x 433 x 652mm | 560 x 516 x 712mm | 560 x 601 x 712mm | 560 x 779 x 712mm |
| Package weight | 6.50kg | 7.00kg | 9.00kg | 9.50kg | 12.50kg | 17.00kg | 21.00kg | 22.00kg | 27.00kg |
| Package quantity | 1 unit | 1 unit | 1 unit | 1 unit | 1 unit | 1 unit | 1 unit | 1 unit | 1 unit |
| Carton dimensions | 550 x 155 x 625mm | 550 x 199 x 625mm | 560 x 255 x 465mm | 560 x 255 x 652mm | 560 x 342 x 652mm | 560 x 433 x 652mm | 560 x 516 x 712mm | 560 x 601 x 712mm | 560 x 779 x 712mm |
| Carton weight | 6.50kg | 7.00kg | 9.00kg | 9.50kg | 12.50kg | 17.00kg | 21.00kg | 22.00kg | 27.00kg |
| Carton quantity | 1 package | 1 package | 1 package | 1 package | 1 package | 1 package | 1 package | 1 package | 1 package |
| Pack plastic weight | 0.03kg | 0.03kg | 0.05kg | 0.05kg | 0.07kg | 0.07kg | 0.07kg | 0.04kg | 0.04kg |
