NRN-1 Huminator Noise Gate Pedal

Huminator is a high quality noise gate pedal for guitar or bass. All analog circuitry guarantees pure signal integrity with Threshold and Decay controls to adjust the gating level and release curve of the gate. Effects that produce the most noise in a chain can be isolated through the send/return loop so that only they are subjected to the noise gate process, leaving other pedals in the chain without any unwanted effect from the gate. A Reduction and Mute switch can be set to completely mute the signal when the pedal is deactivated to prevent unwanted noise from the instrument when it is not being played. Huminator is a professional noise reduction tool that can make all the difference to a multi-pedal setup.

• Mute function to prevent unwanted noise between playing
• Send/return loop to isolate noise producing effects
• Adjustable Threshold and Decay

• Battery 9V PP3 (supplied)
• Power supply Optional 9Vdc 300mA regulated (not supplied)
• Controls Threshold, Decay, Reduction/Mute
• Input impedance 1M Ohms
• Output impedance 10k Ohms
• Dimensions 121 x 77 x 48mm
• Weight 230g
