4 Ohm High Power Sub Drivers
10" sub 4ohm 300Wrms
902.120UK
SUBCASA-10BA
High power handling 4 Ohm low frequency drivers with large diameter voice coil and reinforced cone. Designed for installing into ported or folded cabinets to add high energy sub frequencies and… more
- Direct replacements for CASA series active sub cabinets
4 Ohm High Power Sub Drivers
High power handling 4 Ohm low frequency drivers with large diameter voice coil and reinforced cone. Designed for installing into ported or folded cabinets to add high energy sub frequencies and explosive dynamics in medium to large PA systems.
- Direct replacements for CASA series active sub cabinets
- Weight 3.1kg
- Dimensions 130 x 257mmØ
- Sensitivity 95dB
- Magnet 156 x 80 x 20mm (40oz)
- Voice coil 64mmØ (2.5")
- Frequency response 50Hz - 2kHz
- Power handling : max 500W
- Power handling : rms 300W
- Construction Reinforced paper cone with steel frame basket
- Impedance 4 Ohms
In the Box
- 4 Ohm high power sub woofer driver
