100V line speakers
For many applications, it is necessary to drive many speakers with a single amplifier, giving greater coverage to multiple rooms or over a given area. 100V line is a solution to this problem.
RH Series Rectangular Horn Speakers 100V
952.099UK
RH15V
PA horn speakers with 100V transformer offering several different power settings. The housing is moulded from high impact ABS material to offer maximum protection against physical or weather damage...
- Durable and weatherproof
- Rotary 100V tapping switch
RH Series Rectangular Horn Speakers 100V
PA horn speakers with 100V transformer offering several different power settings. The housing is moulded from high impact ABS material to offer maximum protection against physical or weather damage. Reflex loading and a rectangular flared aperture ensures efficient and directed sound delivery over large areas.
- Durable and weatherproof
- Rotary 100V tapping switch
- IP rating IP66
Versions
| 952.099UK | 952.249UK | |
|---|---|---|
| Power rms | 15W | 40W |
| Power max. | 23W | 60W |
| Frequency response | 275Hz - 7kHz (±3dB) | 180Hz - 7kHz (±3dB) |
| 100V line tappings | 2.5 / 5 / 10 / 15W | 5 / 10 / 20 / 30 / 40W |
| Impedance | 4k / 2k / 1k / 670 Ohms | 2k / 1k / 500 / 330 / 250 Ohms |
| SPL @ 1W/1m | 106dB | 113dB |
| SPL @ rated power | 118dB | 129dB |
| Dimensions | 312 x 255 x 152mm | 450 x 405 x 202mm |
| Weight | 1.48kg | 3.33kg |
