CASA Passive PA Cabinets

178.111UK CASA-10

Full-range passive PA cabinets with high-efficiency drivers loaded into a compact impact-resistant moulded cabinet. Fitted with 2 side handles and a top carrying handle for easy portability or moun...

  • Custom high-efficiency drivers
  • High impact moulded cabinet with side and top handles.
  • 35mm pole mount socket
Description Version Packed
178.109UK
CASA-8 Passive 8" Full Range PA Cabinet 200W
8" 200W Box Label
178.111UK
CASA-10 Passive 10" Full Range PA Cabinet 220W
10" 220W Box Label
178.113UK
CASA-12 Passive 12" Full Range PA Cabinet 280W
12" 280W Box Label

Accessories

Description Version Packed
902.105UK
10" Driver 8 Ohm 250W CASA-10
10" 8ohm 250W Box Label
902.109UK
25mm (1") HF Driver 20Wrms for CASA-8A and CASA-10A
25mm (1") 20Wrms Box Label

CASA Passive PA Cabinets

Full-range passive PA cabinets with high-efficiency drivers loaded into a compact impact-resistant moulded cabinet. Fitted with 2 side handles and a top carrying handle for easy portability or mounting via the integral 35mm pole-mount socket. These cabinets pair perfectly with the CASA series sub cabinets for high energy sound reinforcement.

  • Custom high-efficiency drivers
  • High impact moulded cabinet with side and top handles.
  • 35mm pole mount socket
  • Impedance 8 Ohms
  • Connection 2 x SPK socket

Versions

  178.109UK 178.111UK 178.113UK
Main driver 200mmØ (8") 250mmØ (10") 300mmØ (12")
Voice coil 50mmØ (2") 50mmØ (2") 75mmØ (2.5")
HF driver 25mmØ (1") Ti compression driver 25mmØ (1") Ti compression driver 35mmØ (1.35") Ti compression driver
Power handling : rms 150W 200W 300W
Power handling : max 300W 400W 600W
Dimensions 435 x 278 x 245mm 500 x 310 x 260mm 610 x 375 x 340mm
Weight 8.1kg 9.7kg 11.0kg

Support : articles

Low impedance speakers

Impedance is the effective resistance of an electric circuit or component to alternating current, arising from the combined effects of resistance and reactance. Here we explain the features of low impedance and how it is implemented in a speaker system.

Sunday, 1st January 2017

Speaker system types

Our speaker and amplifier products cover many environments and applications with a focus on clear and efficient sound coverage. Here we discuss the different types of systems

Sunday, 1st January 2017

Power Ratings: RMS vs Max vs Peak

A summary explaining the key differences between RMS, Max and Peak power ratings.

Tuesday, 10th March 2020

In the box

The box for this item contains :

  • CASA series PA cabinet

Downloads

UK Declaration of conformity
For 178.111UK (240KB)
EU Declaration of conformity
For 178.111UK (232KB)
