Soft Start Pure Sine Wave Inverters

652.101UK IPS300-24

These high efficiency power inverters produce a pure sine wave to power 230V mains equipment from a 12V or 24V battery or DC power supply. Perfect for use while camping, in commercial vans/lorries,...

  • Over 90% efficiency
  • Soft start minimises inverter shutdown when using large inductive loads
  • High accuracy output wave form with less than 4% THD
Description Version Packed
652.100UK
12Vdc Pure Sine Wave Inverter 300W
12Vdc 300W Box Label
652.102UK
12Vdc Pure Sine Wave Inverter 600W
12Vdc 600W Box Label
652.104UK
12Vdc Pure Sine Wave Inverter 1000W
12Vdc 1000W Box Label
652.101UK
24Vdc Pure Sine Wave Inverter 300W
24Vdc 300W Box Label

Soft Start Pure Sine Wave Inverters

These high efficiency power inverters produce a pure sine wave to power 230V mains equipment from a 12V or 24V battery or DC power supply. Perfect for use while camping, in commercial vans/lorries, or as a means to convert charged batteries for back-up power in case of a blackout. Ideal for use with TVs, computers, kettles and other everyday appliances.

  • Over 90% efficiency
  • Soft start minimises inverter shutdown when using large inductive loads
  • High accuracy output wave form with less than 4% THD
  • Reverse polarity protection
  • Low/over voltage input protection
  • Short circuit, overload and overheat protection
  • Built in 1000mA USB socket on the 600W & 1000W versions
  • LED and audible fault indicator
  • Supplied with 1 pair of 800mm DC power cables and a spare blade fuse
  • 12V or 24V input versions available, please ensure the correct version is selected for the input power to be used
  • Please note: Ensure the device is well within the inverter output power rating. We recommend using an inverter capable of supplying a minimum of 3 times the device's rated power to avoid damage to the inverter by any current surge (especially for fridges and freezers which can surge up to 7 times the rated power)
  • Power : output 230Vac, 50Hz

Versions

  652.100UK 652.102UK 652.104UK 652.101UK
Continuous power 300W 600W 1000W 300W
Voltage 12V 12V 12V 24V
Input voltage 10.8 - 15.5Vdc 10.8 - 15.5Vdc 10.8 - 15.5Vdc 21.6 - 31Vdc
Standby no load current 0.6A 0.8A 0.8A 0.6A
Cable type Crocodile clip Ring terminal Ring terminal Crocodile clip
Cable terminals 72mm crocodile clip + 6.4/12mm ring 6.4/12mm Ring 8.5/16.5mm Ring 72mm crocodile clip + 6.4/12mm ring
Inverter terminals M6 screws M6 screws M8 screws M6 screws
USB output current n/a 1A 1A n/a
Dimensions 174 x 150 x 55mm 255 x 150 x 70mm 365 x 150 x 70mm 174 x 150 x 55mm
Weight 960g 1.8kg 2.74kg 960g

Downloads

Instruction manual
For 652.101UK (381KB)
UK Declaration of conformity
For 652.101UK (250KB)
EU Declaration of conformity
For 652.101UK (236KB)
