MM240 Mixer Amplifier 2 x 120W

953.030UK MM240

Compact 1U mixer-amp featuring a built-in media player with DAB+ and Bluetooth receiver. 3 mono inputs connect via XLR microphone or line input (switchable). Each of these inputs has switchable +20...

  • DAB+/FM radio tuner
  • Bluetooth receiver with unique serial ID
  • USB/SD audio player
Full description Find retailer
Description Version Packed
953.030UK
MM240 Mixer-amplifier 2 x 120W 		2 x 120W Box Label

MM240 Mixer Amplifier 2 x 120W

Compact 1U mixer-amp featuring a built-in media player with DAB+ and Bluetooth receiver. 3 mono inputs connect via XLR microphone or line input (switchable). Each of these inputs has switchable +20V phantom power for use with condenser microphones or D.I. boxes and channel 1 has a variable priority function. Two stereo auxiliary line inputs are provided on RCA connectors with a stereo line output. Media player operating modes include 3.5mm Aux input, USB audio player, DAB+/FM radio tuner and Bluetooth receiver for playback from a smart phone or tablet. Main left and right speaker outputs are connected using standard Speakon leads. Connect 2 or 4 speakers for a complete music and voice installation or mobile PA system for functions, conferences and fitness classes.

  • DAB+/FM radio tuner
  • Bluetooth receiver with unique serial ID
  • USB/SD audio player
  • Switchable +20V phantom power
  • Variable priority muting for channel 1
  • 24V emergency mute contacts
  • Power supply 100-240Vac, 50/60Hz (IEC)
  • Fuse T3.15A
  • Output power : 4 Ohms 2 x 120Wrms
  • Inputs : mic/line 3 x XLR (bal/unbal)
  • Inputs : aux 2 x L+R RCA
  • Input : line 3.5mm jack to media player
  • Audio source DAB+/FM tuner, USB/SD player, Bluetooth receiver
  • Line output L+R RCA
  • Speaker outputs L+R SPK connector
  • Emergency control 24V contacts mute all except channel 1
  • Phantom power +20V (switchable channels 1-3)
  • Bluetooth version 5.0
  • Controls Media, 3 x Mic/Line, 2 x Aux, Treble, Bass, Master level
  • Rear panel controls Priority muting level, mic/line and phantom DIP switches
  • Input impedance 2.2k Ohms (mic/line), 10k Ohms (aux)
  • Frequency response : mic 20Hz - 18kHz
  • Frequency response : line 14Hz - 20kHz
  • Frequency response : aux 10Hz - 23kHz
  • Input sensitivity : mic/line -45dBV
  • Input sensitivity : aux/line -10dBV
  • Signal to noise ratio : mic 55dB
  • Signal to noise ratio : aux/line 60dB
  • Dimensions 482 x 123 x 44mm
  • Weight 1.96kg

Versions

  953.030UK
Output power rms @ 4 Ohms 2 x 120W

Support : articles

Amplifier Classes

There have been many developments in audio electronics, resulting in different amplifier circuit designs. Such designs can be divided into classes, of which 4 main types are relevant to audio – A, AB, H and D.

Friday, 28th February 2020

Power Ratings: RMS vs Max vs Peak

A summary explaining the key differences between RMS, Max and Peak power ratings.

Tuesday, 10th March 2020

In the box

The box for this item contains :

  • MM240 mixer-amplifier
  • IEC power lead(s)
  • Bluetooth antenna

Downloads

Instruction manual
For 953.030UK (369KB)
