MHS-150UV: 150W LED Orbital U/V Moving Head

150.465UK MHS-150UV

A dazzling moving head comprising 12 powerful 10W RGBW LEDs and 6 U/V LEDs which combine with 360° tilt movement to provide room filling effects from any position. The unit can be operated on auto,...

  • 12 Bright RGBW LEDs combine with 6 U/Vs to provide a dazzling lightshow
  • 360° Head tilt movement provides room filling effects from any location
  • Auto, DMX, sound-to-light and master/slave controls
Description Version Packed
150.465UK
LED Orbital U/V Moving Head
Box Label

MHS-150UV: 150W LED Orbital U/V Moving Head

A dazzling moving head comprising 12 powerful 10W RGBW LEDs and 6 U/V LEDs which combine with 360° tilt movement to provide room filling effects from any position. The unit can be operated on auto, sound-to-light or DMX modes and can be free standing or mounted to trussing using the supplied fixing bracket and is ideal as a centrepiece light in bars, nightclubs and functions.

  • 12 Bright RGBW LEDs combine with 6 U/Vs to provide a dazzling lightshow
  • 360° Head tilt movement provides room filling effects from any location
  • Auto, DMX, sound-to-light and master/slave controls
  • 6 or 11 channel DMX control
  • Power supply 110-240 Vac, 50/60 Hz (IEC)
  • Power consumption 150W
  • Fuse rating F3A
  • LED : power 12x 10W CREE RGBW, 6x 10W U/V
  • Modes Auto, sound, master/slave, DMX512
  • DMX channels 6/11CH
  • PAN range 540°
  • Tilt range 360°
  • Effects LED Spot/Colour chase, U/V
  • Dimensions 325 x 265 x 205mm
  • Weight 4.45kg

In the box

The box for this item contains :

  • MHS-150UV main unit
  • Mounting bracket
  • Safety wire
  • IEC power lead (1.2m)
  • User guide

Videos

QTX 150W Orbital Moving Head

Downloads

Instruction manual
For 150.465UK (203KB)
UK Declaration of conformity
For 150.465UK (249KB)
EU Declaration of conformity
For 150.465UK (238KB)
