Morning Star Overdrive Pedal
173.309UK
NOD-3
Morning Star is a blues drive pedal with a twist. Along with standard Drive, Level and Tone controls, holding the on/off pedal engages a Shine mode, which boosts the high frequencies adding sparkle...
- Drive, Tone and Level controls
- True or buffered bypass operation
- Switchable Shine treble boost effect
Morning Star Overdrive Pedal
Morning Star is a blues drive pedal with a twist. Along with standard Drive, Level and Tone controls, holding the on/off pedal engages a Shine mode, which boosts the high frequencies adding sparkle to cut through a mix. Wide ranging gain adjustment offers tones from natural break-up to thick authentic overdrive. Enough range for blues to full-on rock styles.
- Drive, Tone and Level controls
- True or buffered bypass operation
- Switchable Shine treble boost effect
- Requires 9V center negative DC Power Supply 75mA current draw (Not Supplied)
- Compatible power supply 173.290UK
- Power supply 9Vdc (centre-negative power adaptor required)
- Current consumption 100mA
- Input impedance 1M Ohm
- Output impedance 1k Ohm
- Controls Drive, Tone, Level, On/Off/Mode switch
- Dimensions 94 x 53 x 51mm
- Weight 174g
In the box
The box for this item contains :
- Morning Star overdrive pedal
