Compact & lightweight speaker cabinets designed for multi-purpose sound reinforcement. These shockproof moulded enclosures feature M8/M6 fixing points, allowing them to be arrayed in various combin...
Compact & lightweight speaker cabinets designed for multi-purpose sound reinforcement. These shockproof moulded enclosures feature M8/M6 fixing points, allowing them to be arrayed in various combinations to suit most applications from small halls to large nightclubs.
| 178.210UK | 178.211UK | 178.212UK | 178.213UK | |
|---|---|---|---|---|
| Model | QR8 | QR10 | QR12 | QR15 |
| Power rms | 100W | 150W | 200W | 250W |
| Power max. | 200W | 300W | 400W | 500W |
| Woofer | 200mm (8'') | 250mm (10'') | 300mm (12'') | 380mm (15'') |
| Frequency response | 55Hz - 20kHz | 50Hz - 20kHz | 48Hz - 20kHz | 45Hz - 20kHz |
| SPL @ 1W/1m | 93dB | 95dB | 98dB | 101dB |
| Connector | 1 x SPK | 2 x SPK | 2 x SPK | 2 x 4 wire SPK |
| Dimensions : W(front/rear) x H x D | 290/150 x 400 x 220mm | 320/180 x 470 x 260mm | 350/180 x 570 x 300mm | 430/250 x 680 x 360mm |
| Weight | 4.9kg | 6.4kg | 9.8kg | 14.2kg |
