Speaker system types
Our speaker and amplifier products cover many environments and applications with a focus on clear and efficient sound coverage. Here we discuss the different types of systems
PS Series Pendant Speakers - Wide Angle
952.429UK
PS65-W
Wide dispersion spheroid 2-way pendant speakers for use with high ceilings where regular ceiling speakers would be positioned too high to be efficient. Each has a rotary switch on top for selecting...
- Supplied with 4.5m cable and cable hook for hanging
- Selector for 4 x 100V line tappings + 8 ohms
PS Series Pendant Speakers - Wide Angle
Wide dispersion spheroid 2-way pendant speakers for use with high ceilings where regular ceiling speakers would be positioned too high to be efficient. Each has a rotary switch on top for selecting 100V line tappings and 8 ohms operation.
- Supplied with 4.5m cable and cable hook for hanging
- Selector for 4 x 100V line tappings + 8 ohms
Specification : Versions
| 952.426UK | 952.427UK | 952.429UK | 952.430UK | |
|---|---|---|---|---|
| Colour | White | Black | White | Black |
| Speaker size | 125mm (5") | 125mm (5") | 165mm (6.5") | 165mm (6.5") |
| Dispersion angle | 140° | 140° | 140° | 140° |
| Rated power at 8 Ohms | 20W | 20W | 30W | 30W |
| Frequency response | 50Hz - 20kHz | 50Hz - 20kHz | 40Hz - 20kHz | 40Hz - 20kHz |
| Impedance : 100V | 500, 1k, 2k, 4k Ohms | 500, 1k, 2k, 4k Ohms | 333, 666, 1.3k, 2.6k Ohms | 333, 666, 1.3k, 2.6k Ohms |
| Tappings | 20W, 10W, 5W,2.5W + 8 Ohms | 20W, 10W, 5W,2.5W + 8 Ohms | 30W, 15W, 7.5W, 3.75W + 8 Ohms | 30W, 15W, 7.5W, 3.75W + 8 Ohms |
| Sensitivity | 89dB | 89dB | 88dB | 88dB |
| Dimensions | 180 x 245mmØ | 180 x 245mmØ | 195 x 270mmØ | 195 x 270mmØ |
| Weight | 2.366kg | 2.366kg | 2.916kg | 2.916kg |
Trade information
| 952.426UK | 952.427UK | 952.429UK | 952.430UK | |
|---|---|---|---|---|
| Barcode / EAN | 5015972071502 | 5015972071519 | 5015972071526 | 5015972071533 |
| Tariff code | 8518210000 | 8518210000 | 8518210000 | 8518210000 |
| Country of Origin | CN | CN | CN | CN |
| Package type | Gift Box | Gift Box | Gift Box | Gift Box |
| Package dimensions | 286 x 286 x 246mm | 286 x 286 x 246mm | 319 x 315 x 259mm | 319 x 315 x 259mm |
| Package weight | 2.80kg | 2.80kg | 3.00kg | 3.00kg |
| Package quantity | 1 unit | 1 unit | 1 unit | 1 unit |
| Carton dimensions | 590 x 590 x 510mm | 590 x 590 x 510mm | 330 x 655 x 535mm | 330 x 655 x 535mm |
| Carton weight | 22.40kg | 14.40kg | 12.00kg | 12.00kg |
| Carton quantity | 8 packages | 8 packages | 4 packages | 4 packages |
| Pack paper weight | 0.23kg | 0.22kg | 0.29kg | 0.27kg |
| Pack plastic weight | 0.02kg | 0.02kg | 0.02kg | 0.02kg |
