DM-8 Digital Messaging Unit

953.053UK DM-8

1U rack-mount digital messaging unit for scheduled audio playback. Audio files are stored on a removable SD card and may be transferred by inserting into a PC or directly recorded on the DM-8. Sche...

  • Up to 99 audio tracks stored on SD card
  • Up to 99 schedule events stored on SD card
  • Schedule file editable using free PC software
Description Version Packed
953.053UK
DM-8 Digital Messaging Unit
Box Label

DM-8 Digital Messaging Unit

1U rack-mount digital messaging unit for scheduled audio playback. Audio files are stored on a removable SD card and may be transferred by inserting into a PC or directly recorded on the DM-8. Schedules are also stored on the SD media as a separate file, which can be edited with a PC and stored for backup. Separate SD cards may be saved with different audio messages and schedules and swapped for different routines. A mic/line input can be used for recording or for live announcements which can override SD playback. A BGM line input is provided for background music playback with its own level control and is muted when messages are playing or during paging. Up to 99 schedules can be programmed to play a particular audio file from the SD card, set by 24 hour time and day(s) of the week. The DM-8 can be added to any sound system to provide automated playback of timed announcements, music or audio alerts.

  • Up to 99 audio tracks stored on SD card
  • Up to 99 schedule events stored on SD card
  • Schedule file editable using free PC software
  • Mic/Line input for recording or live announcements
  • BGM line input for background music
  • Power supply 100-240Vac, 50/60Hz or 24Vdc
  • Fuse T1AL 250V
  • Inputs Paging mic/line (XLR or terminals), BGM (RCA)
  • Output Mono balanced terminal or unbalanced RCA
  • Audio source Internal SD card player
  • Time setting 99 programmable schedules - 24 hour + day(s) setting
  • Mic/line channel controls Mic/Line level, Phantom power on/off
  • Phantom power +20V
  • Input impedance 2.2k Ohms (mic/line)
  • Controls Page/Rec, Mic, Clock Set, Schedule, Message 1-8, Output, Power on/off
  • Trigger Message 1-8, Stop & Ground contacts
  • SD card requirements 4-32GB FAT32 (full size or with adaptor)
  • Dimensions 483 x 150 x 44mm
  • Weight 1.65kg

In the box

The box for this item contains :

  • DM-8 digital messaging unit
  • IEC mains lead(s)

Downloads

Instruction manual
For 953.053UK (484KB)
UK Declaration of conformity
For 953.053UK (250KB)
EU Declaration of conformity
For 953.053UK (240KB)
Schedule Software
DM-8 schedule editor & librarian software
