63 Diamond Overdrive Pedal

173.237UK NRO-6

The Reissue series 63 Diamond pedal offers players a range of overdrive that emulates the sound of a classic British 30-watt class-A valve amplifier, much-revered by guitarists since 1959 for its t...

  • Classic British class-A overdrive tones
  • Authentic Volume, Master and Cut controls
  • Top boost switch to add bite
Description Version Packed
173.237UK
63 Diamond Overdrive Pedal
63 Diamond Gift Box

63 Diamond Overdrive Pedal

The Reissue series 63 Diamond pedal offers players a range of overdrive that emulates the sound of a classic British 30-watt class-A valve amplifier, much-revered by guitarists since 1959 for its tonally rich clean and crunchy overdrive sound. The styling of the 63 Overdrive is a nod towards the cabinet that stood behind the bands of the British blues invasion and rock bands of the 1970's through to present day guitar bands. Volume and Master controls let you dial in the drive, with a tone Cut control just like the real amplifier. A Top boost switch introduces additional bite and was a later addition to the design in 1963, which is where this pedal gets its name. Invoking 60's British cool in a single pedal was never this easy before.

  • Classic British class-A overdrive tones
  • Authentic Volume, Master and Cut controls
  • Top boost switch to add bite
  • True bypass switching
  • Batteries 9V PP3 (supplied)
  • Power supply Optional 9Vdc 300mA regulated (not supplied)
  • Controls Volume, Master, Cut, Top Boost & foot switch
  • Input impedance 1M Ohms
  • Output impedance 10k Ohms
  • Dimensions 121 x 77 x 48mm
  • Weight 230g

In the box

The box for this item contains :

  • 63 Diamond overdrive pedal
  • 9V PP3 battery

Downloads

Instruction manual
For 173.237UK (1.9MB)
UK Declaration of conformity
For 173.237UK (246KB)
EU Declaration of conformity
For 173.237UK (237KB)
