LA Series Induction Loop Amplifiers

952.867UK LA-600 mkII

An induction amplifier for driving a cable loop around a room to provide assisted listening for hearing aid users. Front panel controls are adjusted using a screwdriver including level controls for...

  • Suitable for most standard hearing aids
  • Mic/line level switch for each input
  • Phantom power switch for each input
Description Version Packed
952.864UK
LA-300 mkII induction loop amplifier
300m² Box Label
952.867UK
LA-600 mkII induction loop amplifier
600m² Box Label

Accessories

Description Version Packed
952.347UK
CBM20 Ceiling Boundary Mic
CBM20 Box Label
952.855UK
LR2 induction loop receiver
Box Label

LA Series Induction Loop Amplifiers

An induction amplifier for driving a cable loop around a room to provide assisted listening for hearing aid users. Front panel controls are adjusted using a screwdriver including level controls for the 3 mic/line channels, bass, treble and loop current. Designed to provide hearing assistance in public and commercial buildings.

  • Suitable for most standard hearing aids
  • Mic/line level switch for each input
  • Phantom power switch for each input
  • Tamper proof channel volume, bass & treble and loop current level controls
  • Adjustable metal loss correction
  • Alarm contacts for built-in siren
  • Priority switchable for channel 1
  • Peak current LED indication
  • 19" rack mountable
  • Power supply 110/240Vac, 50/60Hz (IEC)
  • Frequency response 50Hz - 5kHz (±3dB)
  • Input sensitivity : line -6dBu/6k Ohms
  • Input sensitivity : mic -56dBu/2k Ohms
  • Signal to noise ratio 75dB (line), 60dB (mic)
  • THD <1%

Versions

  952.864UK 952.867UK
Fuse T1A 250V T2A 250V
Rack height 1U 2U
Area coverage 300m² max. 600m² max.
Dimensions 483 x 235 x 44mm 483 x 235 x 88mm
Weight 3.80kg 4.22kg

Downloads

Instruction manual
For 952.867UK (526KB)
UK Declaration of conformity
For 952.867UK (251KB)
EU Declaration of conformity
For 952.867UK (241KB)
