Universal 24Vdc Power Supplies

153.762UK PS200-24

A range of IP67 rated 24Vdc power supplies, available in a range of power output ratings from 30W to 300W, suitable for both indoor and outdoor LED Tape & lighting installations. For professional u...

  • Ideal for 24Vdc LED Tape and Lighting Installations
  • 1 or 2 outputs for loop output connection
  • Waterproof IP67 rated
Description Version Packed
153.757UK
Power Supply 24Vdc 1.25A 30W
24Vdc 1.25A 30W Box Label BW
153.758UK
Power Supply 24Vdc 1.875A 45W
24Vdc 1.875A 45W Box Label BW
153.759UK
Power Supply 24Vdc 2.50A 60W
24Vdc 2.50A 60W Box Label BW
153.760UK
Power Supply 24Vdc 4.16A 100W
24Vdc 4.16A 100W Box Label BW
153.761UK
Power Supply 24Vdc 6.25A 150W
24Vdc 6.25A 150W Box Label BW
153.762UK
Power Supply 24Vdc 8.33A 200W
24Vdc 8.33A 200W Box Label BW
153.763UK
Power Supply 24Vdc 10.4A 250W
24Vdc 10.4A 250W Box Label BW
153.764UK
Power Supply 24Vdc 12.5A 300W
24Vdc 12.5A 300W Box Label BW

Universal 24Vdc Power Supplies

A range of IP67 rated 24Vdc power supplies, available in a range of power output ratings from 30W to 300W, suitable for both indoor and outdoor LED Tape & lighting installations. For professional use only.

  • Ideal for 24Vdc LED Tape and Lighting Installations
  • 1 or 2 outputs for loop output connection
  • Waterproof IP67 rated
  • Short circuit protection
  • Professional use power supplies
  • Output voltage 24Vdc
  • IP rating IP67

Versions

  153.757UK 153.758UK 153.759UK 153.760UK 153.761UK 153.762UK 153.763UK 153.764UK
Input voltage 100-250Vac, 50/60Hz 170-250Vac, 50/60Hz 170-250Vac, 50/60Hz 170-250Vac, 50/60Hz 170-250Vac, 50/60Hz 170-250Vac, 50/60Hz 170-250Vac, 50/60Hz 185-250Vac, 50/60Hz
Output feeds 1 1 1 1 2 2 1 1
Total power output 30W 45W 60W 100W 150W 200W 250W 300W
Current 1.25A 1.87A 2.5A 4.17A 6.25A 8.33A 10.42A 12.5A
Dimensions 221 x 30 x 20mm 252 x 40 x 22mm 159 x 70 x 45mm 240 x 70 x 45mm 245 x 70 x 46mm 231 x 133 x 64mm 233 x 120 x 56mm 287 x 108 x 65mm
Weight 250g 400g 782g 1.25kg 2.8kg 2.8kg 3kg 3.2kg

Downloads

Instruction manual
For 153.762UK (169KB)
UK Declaration of conformity
For 153.762UK (250KB)
EU Declaration of conformity
For 153.762UK (238KB)
