Full Motion Double Arm TV Wall Bracket for Curved & Flat Screens 32" to 65"

129.561UK CC601

This full motion TV wall bracket has a special angle adjustable mount which will accommodate both flat and curved screens. Its suitable for screen sizes from 32" to 65" or with VESA mounting patter...

  • Suitable for 32" to 65" sized flat or curved TV screens
  • Compatible with VESA mounting patterns up to 600x400mm
  • -2° to 12° tilt mechanism
Full description Video Find retailer
Description Version Packed
129.561UK
Full Motion Curved & Flat TV Wall Bracket 32" to 65" 		600x400 Max (32-65") Gift Box

Full Motion Double Arm TV Wall Bracket for Curved & Flat Screens 32" to 65"

This full motion TV wall bracket has a special angle adjustable mount which will accommodate both flat and curved screens. Its suitable for screen sizes from 32" to 65" or with VESA mounting patterns up to a maximum of 600x400mm.

  • Suitable for 32" to 65" sized flat or curved TV screens
  • Compatible with VESA mounting patterns up to 600x400mm
  • -2° to 12° tilt mechanism
  • 90° pan from wall plate
  • 45° swivel from arm joint
  • Sturdy dual arm support
  • Integrated cable management system
  • Installation hardware included
  • Max. VESA 600 x 400
  • Max. weight load 45kg
  • Screen size 32" - 65"
  • Distance from wall 74 - 514mm
  • Tilt range -2° to 12°
  • Wall plate dimensions 477 x 394mm
  • Bracket dimensions 648 x 440mm
  • Weight 7.35kg
  • TV fixing screws provided 4 x M4 25mm, 4 x M5 25mm, 4 x M6 25mm, 4 x M8 25mm

Videos

AV:LINK TV Brackets and Projector Brackets Overview

Downloads

Instruction manual
For 129.561UK (480KB)
