QX Series Passive Speaker Cabinets

178.223UK QX15

Compact, durable speaker cabinets designed for multi-purpose sound reinforcement. The sturdy moulded enclosures feature flying points for mounting from suspension wires and a 35mm socket for pole m...

  • SPK connectors
  • Rigid steel grille and easy-carry handle
  • Titanium compression driver
Description Version Packed
178.222UK
QX12 Passive Speaker
12" Black Box Printed
178.223UK
QX15 Passive Speaker
15" Black Box Printed
179.222UK
QX12-White Passive Speaker
12" White Box Printed

QX Series Passive Speaker Cabinets

Compact, durable speaker cabinets designed for multi-purpose sound reinforcement. The sturdy moulded enclosures feature flying points for mounting from suspension wires and a 35mm socket for pole mounting. Deep porting and efficient drivers enable these cabinets to accurately reproduce a balanced and evenly dispersed sound output.

  • SPK connectors
  • Rigid steel grille and easy-carry handle
  • Titanium compression driver
  • Tuned ported cabinet for efficient bass output
  • 35mm internal pole-mounting

Specification : Common

  • Impedance 8 Ohms
  • Pole mounting 35mm integral top-hat
  • Connection 2 x SPK

Specification : Versions

  178.222UK 178.223UK 179.222UK
Model QX12 QX15 QX12-WHITE
Power rms 200W 250W 200W
Power max. 400W 500W 400W
Woofer 300mm (12'') 380mm (15'') 300mm (12'')
Frequency response 48Hz - 20kHz 45Hz - 20kHz 48Hz - 20kHz
SPL @ 1W/1m 98dB 101dB 98dB
Dimensions 565 x 345 x 325mm 675 x 420 x 395mm 565 x 345 x 325mm
Weight 9.8kg 14.2kg 9.8kg

Trade information

  178.222UK 178.223UK 179.222UK
Barcode / EAN 5015972218099 5015972218112 5015972215555
Package type Box Printed Box Printed Box Printed
Package dimensions 405 x 615 x 400mm 480 x 735 x 455mm 405 x 615 x 400mm
Package weight 9.80kg 14.20kg 9.80kg
Package quantity 1 unit 1 unit 1 unit
Carton dimensions 405 x 615 x 400mm 480 x 735 x 455mm 405 x 615 x 400mm
Carton weight 9.80kg 14.20kg 9.80kg
Carton quantity 1 package 1 package 1 package

In the box

The box for this item contains :

  • QX series passive speaker cabinet
